# Run pqm4 tests and benchmarks ## In this learning path - [Introduction](https://learn.arm.com/learning-paths/embedded-and-microcontrollers/pqc_pqm4/) - [Understand pqm4 and post-quantum cryptography](https://learn.arm.com/learning-paths/embedded-and-microcontrollers/pqc_pqm4/introduction/) - [Set up the pqm4 development environment](https://learn.arm.com/learning-paths/embedded-and-microcontrollers/pqc_pqm4/setup-installation/) - [Run pqm4 tests and benchmarks](https://learn.arm.com/learning-paths/embedded-and-microcontrollers/pqc_pqm4/running-tests-and-benchmarks/) - [Add a KEM implementation to pqm4](https://learn.arm.com/learning-paths/embedded-and-microcontrollers/pqc_pqm4/adding-new-schemes/) - [Next Steps](https://learn.arm.com/learning-paths/embedded-and-microcontrollers/pqc_pqm4/_next-steps/) ## Understand generated pqm4 binaries After building pqm4, a set of binaries is generated for each scheme and implementation. You can use these binaries to verify correctness, measure performance, and analyze resource usage on your Cortex-M4 board or in QEMU. For example, building ML-KEM-768 produces binaries with names in this pattern: ``` __output__ bin/crypto_kem_ml-kem-768__.bin ``` The `` field identifies the implementation variant. The exact suffix depends on the scheme: - `m4fspeed`: Cortex-M4F implementation optimized for speed (used by ML-KEM) - `m4fstack`: Cortex-M4F implementation optimized for stack size (used by ML-KEM) - `m4f`: Cortex-M4F implementation used by some schemes such as BIKE - `clean`: clean reference implementation from PQClean The `clean` variant uses a different file prefix: `mupq_pqclean_crypto_kem__clean_.elf` The `` field identifies what the binary measures. The following section explains each type and how you can run them. ## Flash and run a generated binary How you run a binary depends on whether you are using a physical board or QEMU. ### Physical board Flash the binary and read the serial output. Flash the binary: ``` st-flash write bin/.bin 0x8000000 ``` Read the output from the board: ``` python3 hostside/host_unidirectional.py ``` Press the RESET button on the board to trigger execution and see the output. ### QEMU Run the corresponding ELF file directly. ``` qemu-system-arm -M mps2-an386 -nographic -semihosting -kernel elf/.elf ``` To exit QEMU, press `Ctrl+A` then `X`. ### Run a test binary The test binary verifies that a scheme works correctly end to end. #### Physical board Flash the ML-KEM-768 test binary on a physical board: ``` st-flash write bin/crypto_kem_ml-kem-768_m4fspeed_test.bin 0x8000000 ``` #### QEMU Run the ML-KEM-768 test binary on QEMU: ``` qemu-system-arm -M mps2-an386 -nographic -semihosting -kernel elf/crypto_kem_ml-kem-768_m4fspeed_test.elf ``` It generates a keypair, performs encapsulation and decapsulation, and checks that both sides derive the same shared secret. It also tests failure cases such as an invalid secret key or invalid ciphertext. The output after running the binary is similar to: ``` __output__ ========================== __output__ DONE key pair generation! __output__ DONE encapsulation! __output__ DONE decapsulation! __output__ OK KEYS __output__ __output__ + __output__ ... __output__ OK invalid sk_a __output__ __output__ + __output__ OK invalid ciphertext __output__ __output__ + __output__ # ``` ### Run a speed binary The speed binary measures execution time in CPU cycles for each operation. #### Physical board Flash the ML-KEM-768 speed binary on a physical board: ``` st-flash write bin/crypto_kem_ml-kem-768_m4fspeed_speed.bin 0x8000000 ``` #### QEMU Run the ML-KEM-768 speed binary on QEMU: ``` qemu-system-arm -M mps2-an386 -nographic -semihosting -kernel elf/crypto_kem_ml-kem-768_m4fspeed_speed.elf ``` The output after running the binary is similar to: ``` __output__ ========================== __output__ keypair cycles: __output__ 123456 __output__ __output__ encaps cycles: __output__ 234567 __output__ __output__ decaps cycles: __output__ 210000 __output__ = ``` ### Run a hashing binary The hashing binary measures how many cycles are spent in symmetric primitives such as SHA-2, SHA-3, and AES. The number of cycles shows how much of the overall algorithm cost comes from hashing. #### Physical board Flash the ML-KEM-768 hashing binary on a physical board: ``` st-flash write bin/crypto_kem_ml-kem-768_m4fspeed_hashing.bin 0x8000000 ``` #### QEMU Run the ML-KEM-768 hashing binary on QEMU: ``` qemu-system-arm -M mps2-an386 -nographic -semihosting -kernel elf/crypto_kem_ml-kem-768_m4fspeed_hashing.elf ``` The output after running the binary is similar to: ``` __output__ ========================== __output__ keypair hash cycles: __output__ 50000 __output__ __output__ encaps hash cycles: __output__ 80000 __output__ __output__ decaps hash cycles: __output__ 75000 __output__ = ``` ### Run a stack binary The stack binary measures peak stack memory usage for each operation. #### Physical board Flash the ML-KEM-768 stack binary on a physical board: ``` st-flash write bin/crypto_kem_ml-kem-768_m4fspeed_stack.bin 0x8000000 ``` #### QEMU Run the ML-KEM-768 stack binary on QEMU: ``` qemu-system-arm -M mps2-an386 -nographic -semihosting -kernel elf/crypto_kem_ml-kem-768_m4fspeed_stack.elf ``` The output after running the binary is similar to: ``` __output__ ========================== __output__ keypair stack usage: __output__ 2048 __output__ __output__ encaps stack usage: __output__ 3072 __output__ __output__ decaps stack usage: __output__ 2800 __output__ # ``` > Stack measurement might not work correctly on some boards due to platform-specific memory layout. Memory allocated outside functions, such as public keys and ciphertexts, is not included in these measurements. ### Run a test vectors binary The test vectors binary generates deterministic test vectors using a fixed random seed. These are used to validate correctness and compare different implementations against each other. #### Physical board Flash the ML-KEM-768 test vectors binary on a physical board: ``` st-flash write bin/crypto_kem_ml-kem-768_m4fspeed_testvectors.bin 0x8000000 ``` #### QEMU Run the ML-KEM-768 test vectors binary on QEMU: ``` qemu-system-arm -M mps2-an386 -nographic -semihosting -kernel elf/crypto_kem_ml-kem-768_m4fspeed_testvectors.elf ``` To compare the on-device vectors against host-generated reference vectors, use the `testvectors.py` script described in the automated testing section. ## Use scripts to automate testing and benchmarking pqm4 includes Python scripts that automate flashing, running, and checking results across multiple implementations. Before running any Python scripts in this section, make sure your virtual environment is active: ``` source venv/bin/activate ``` ### Run functional tests The `test.py` script runs the test binary on your chosen platform and checks correctness automatically. #### NUCLEO-L476RG Run functional tests on NUCLEO-L476RG: ``` python3 test.py -p nucleo-l476rg --uart /dev/tty.usbmodemXXXX ml-kem-768 ``` #### QEMU Run functional tests on QEMU: ``` python3 test.py -p mps2-an386 ml-kem-768 ``` The output after running functional tests is similar to: ``` __output__ ml-kem-768 - m4fspeed SUCCESSFUL __output__ ml-kem-768 - m4fstack SUCCESSFUL __output__ ml-kem-768 - clean SUCCESSFUL __output__ test: 100%|#############################################| 3/3 [00:12<00:00, 4.29s/it, ml-kem-768 - clean] ``` ### Run test vectors The `testvectors.py` script generates test vectors on your chosen platform and compares them with host-side results. #### NUCLEO-L476RG Run test vector validation on NUCLEO-L476RG: ``` python3 testvectors.py -p nucleo-l476rg --uart /dev/tty.usbmodemXXXX ml-kem-768 ``` #### QEMU Run test vector validation on QEMU: ``` python3 testvectors.py -p mps2-an386 ml-kem-768 ``` The output after running test vector validation is similar to: ``` __output__ ml-kem-768 - m4fspeed SUCCESSFUL __output__ ml-kem-768 - m4fstack SUCCESSFUL __output__ ml-kem-768 - clean SUCCESSFUL __output__ test: 100%|#############################################| 3/3 [00:12<00:00, 4.29s/it, ml-kem-768 - clean] ``` ### Run benchmarks The `benchmarks.py` script runs speed and stack benchmarks and stores the results in a `benchmarks/` directory. #### NUCLEO-L476RG Run benchmarks on NUCLEO-L476RG: ``` python3 benchmarks.py -p nucleo-l476rg --uart /dev/tty.usbmodemXXXX ml-kem-768 ``` #### QEMU Run benchmarks on QEMU: ``` python3 benchmarks.py -p mps2-an386 ml-kem-768 ``` The output of running benchmarks is similar to: ``` __output__ speed: 33%|################ | 1/3 [00:20<00:40, 20.00s/it, ml-kem-768 - m4fspeed] __output__ speed: 66%|########################### | 2/3 [00:40<00:20, 20.00s/it, ml-kem-768 - m4fstack] __output__ speed: 100%|##############################| 3/3 [01:00<00:00, 20.00s/it, ml-kem-768 - clean] ``` Results are saved to `benchmarks.csv`. The screenshot shows an example of the benchmark output: ![Example benchmark results for ML-KEM-768](https://learn.arm.com/learning-paths/embedded-and-microcontrollers/pqc_pqm4/./benchmarks.png) *Example benchmark results for ML-KEM-768* ## What you’ve accomplished and what’s next You’ve now run functional tests, measured cycle counts and stack usage, and validated test vectors for a post-quantum KEM on Arm Cortex-M4. You can apply the same steps to any scheme included in pqm4 by substituting the scheme name in the binary path or script arguments. Next, you’ll learn how to add a new cryptographic scheme or implementation to the pqm4 framework.
